Product Name: Hybrid Inverter
Model Numer: CSEH-10K-T4001AL-E
Battery Voltage Range (V): 48 Vd.v(40V-60V)
Max.Charging/Discharging Current (A): 220A/220A
Vmax. PV(absolute max.): DC 800V
MPPT Voltage Range: DC 160-650V
Max. Input Current: 36Ad.c.+20Ad.c.
Isc PV(absolute max): 54Ad.c.+30Ad.c.
Rated Output Power(Grid): 10 kW
Max.Output apparent Power: 11kWA
