TECHNICAL PARAMETER
Rated power: 7 kw (Adjustable)
Rated voltage: 230VAC (single phase)
LV Distribution: TNa nd IT power system
Voltage Range: 230VAC±20%
Rated Frequency: 50HZ/60HZ
Frequency Range: 50 HZ±1%
Rated current: 32A (Adjustable)
Charging Mode: Mode3 , case B
Dimensions (WX L X H): 160x210x126 mm
Model order code: EC-07/B
Effective：＞99%
Standby power consumption： <5w
Noise: s45dB
IP Degree:IP54
IK Degree: IK08
Earth Leakage protection: Type B
Ambient Temperature:-25~50℃
Operating Humidity: 5%~98%
Standards: IEC 61851-1 , IEC61851-22, IEC 62196-2
Connector standard: TYPE 2 socket meet IEC 62196-1 and IEC 62196-2
Certificate: CE byTUV Rheinland
HIGHLIGHTS
01.Dimensions (H X W X D): 210*160*126
02.Simple electrical install.
03.Earth Leakage protection:6mA DC+30mA AC leakage detection is already in the charger, no Type B RCD required.
04.Compatible with 100 mm² and 6 mm²power wire.
05.Wi-Fi connection: you can watch and setup the charger via Wi-Fi.
06.The electrical lock, the standard requited and is safe for your using.
07.Custumed color, the shell can be colored various color. Universal socket.
08.Power Rating: It can be adjust via Wi-Fi or DIP switch.
